Juniper QSFP-100G-ZRBD-D Compatible QSFP28 100G BiDi 1309.14nm-Tx/1273.55nm-Rx 80km SMF Simplex LC With Dual CDR DDM/DOM Optics Transceiver

Name: Juniper QSFP-100G-ZRBD-D Compatible QSFP28 100G BiDi 1309.14nm-Tx/1273.55nm-Rx 80km SMF Simplex LC With Dual CDR DDM/DOM Optics Transceiver
Brand: INPHE.COM - DCI | HPC | Enterprise Network
SKU: 7070149163
Price: 1599 USD
Availability: InStock

#7070149163

US$1,599.00

INPHE: QSFP28-100G-BX80D

Received successfully

Coupon Code

CONTINUE SHOPPING

Compatible Brands:

Cisco Juniper

Compatible Models:

QSFP-100G-ZRBD-D Customized

QTY:

Specifications

Vendor Name	INPHE	Part Number	QSFP-100G-BX80D
Form Factor	QSFP28	Max Data Rate	103.1Gbps
Wavelength	1295.56, 1300.05, 1304.58, 1309.14nm-Tx 1273.54, 1277.89, 1282.26, 1286.66nm-Rx	Max Distance	80km
Connector	Simplex LC	Transmitter Type	EML
Cable Type	SMF	Receiver Type	SOA+PIN
Transmitter Power	+2.0 ~ +7.0dBm	Receiver Sensitivity	< -28.0dBm
Protocols	QSFP28 MSA Compliant	Operation Temperature	0 to 70°C (32 to 158°F)
DDM/DOM	Supported	Warranty	3 Years
